DS200CPCAG1A Control Board Origina New In Stock
- Part number：DS200CPCAG1A
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: DS200CPCAG1A – GE Mark V CPCA Contactor Pilot Control Board
GE DS200CPCAG1A (CPCA) Contactor Pilot Relay Card for Speedtronic Mark V Gas & Steam Turbine Control System
DS200CPCAG1A is the fully assembled CPCA Contactor Pilot board under GE Speedtronic Mark V platform, base bare PCB substrate is DS200CPCAG1, suffix A represents standard finished assembly revision. It is a compact auxiliary relay control daughterboard, serving as the signal execution bridge between main CPU rack and field power contactors, responsible for receiving logic switch commands from the main control board, driving built-in 24VDC power relay to control pull-in/release of turbine start-stop, oil pump, hydraulic lock and safety circuit contactors, while feeding back contactor on-off status signals to the main controller. Compatible with Mark V turbine main control cabinet, EX2000 excitation cabinet and DC2000 medium voltage drive racks, matches DS200CPU, DS200AAHA and DS200ACNA series communication boards.
Core Technical Specifications
- Part Number: DS200CPCAG1A | Abbreviation: CPCA | Brand: General Electric | Applicable Platform: Speedtronic Mark V LM
- Version Distinction: DS200CPCAG1 = blank bare PCB without components; DS200CPCAG1A = fully populated standard assembly; DS200CPCAG1ABB = upgraded reinforced assembly variant
- Onboard Power Relay: Built-in 24VDC socket type SPDT relay, rated contact current 15A for contactor pilot driving
- External Wiring Terminals: 4 groups green terminal blocks supporting up to 12 signal wires for field contactor wiring
- Internal Connectors: 12-pin main backplane signal connector, 2 auxiliary 2-pin power signal terminals
- Rack Supply Power: 24VDC auxiliary control power supplied by Mark V rack power module
- Signal Circuit: Integrated RC filter, surge suppression capacitor and optocoupler isolation to resist power cabinet EMI interference
- PCB Protection: Factory standard conformal coating, dust-proof, moisture-proof and anti-corrosive gas treatment
- Mounting Form: Small-size auxiliary plug-in daughterboard, no independent main rack slot occupied
- Physical Dimension: 102 × 88 mm | Net Weight: Approx. 120g, compact lightweight layout
- Operating Temperature: -30°C ~ +65°C | Storage Temperature: -40°C ~ +85°C
- Certifications: CE, UL industrial EMC anti-interference, power generation safety standard compliance
- Hardware Feature: No manual configurable jumpers, fixed circuit design to avoid field misconfiguration risks
Main Functional Features
- Contactor pilot drive core function: Convert low-power logic control signals from main CPU into high-current relay output to control field power contactors for turbine auxiliary equipment
- Bidirectional signal transmission: Receive control commands from rack backplane, feed back contactor actual on-off state to main controller for closed-loop logic judgment
- Built-in surge absorption and differential isolation circuit, effectively eliminate voltage spikes generated by contactor coil switching in high-voltage cabinet environment
- Simplified fixed circuit design without jumpers, reduce on-site wiring and parameter misoperation faults during maintenance
- Complete signal self-diagnosis circuit, real-time detect board power loss, relay coil open circuit and terminal wiring disconnection faults
- Compact daughterboard structure, can be stacked and installed inside control rack to save cabinet internal layout space
- Fully compatible with Mark V main CPU board, AAHA ARCNET hub board and ACNA excitation communication board to form complete control logic loop
- Supports power-off replacement during unit maintenance, no full unit shutdown required under redundant rack configuration
Application Industries
- Combined Cycle & Thermal Power Plant: Mark V gas/steam turbine main control cabinet contactor pilot control auxiliary board
- Hydropower Station: Large generator EX2000 excitation cabinet oil pump and hydraulic lock contactor signal control unit
- Oil & Gas Industry: Offshore platform and gathering station turbine generator auxiliary drive contactor control spare part
- Industrial Cogeneration Station: Reciprocating engine generator set safety shutdown circuit relay drive board
- Equipment Retrofit & Maintenance: Direct replacement spare assembly for aging Mark V CPCA contactor pilot control modules
