PPA322B HIEE300016R2 HIEE400235R1 Analog I/O Module--KIMI

Part number：PPA322B HIEE300016R2 HIEE400235R1
Product Origin：Sweden
HS CODE：8537109021
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB PPA322B | 16AI/8AO Analog I/O Module (HIEE300016R2 & HIEE400235R1)

Symphony Plus DCS-Certified Analog Signal Acquisition & Control with Signal Conditioning & Communication Adapter Assemblies

1. Product Overview

The ABB PPA322B is a high-precision analog I/O module integrated with HIEE300016R2 (signal conditioning assembly) and HIEE400235R1 (communication adapter assembly), specifically designed for ABB Symphony Plus Distributed Control Systems (DCS) in industrial process automation. It combines 16 analog input (AI) channels and 8 analog output (AO) channels to enable accurate acquisition of field signals (temperature, pressure, flow, level) and precise control of actuators (control valves, variable frequency drives). The HIEE300016R2 assembly provides 24-bit Sigma-Delta ADC signal conditioning, 2.5kV AC channel isolation, and support for diverse input signals (4-20mA DC, 0-10V DC/±5V DC, PT100, K-type thermocouple), while the HIEE400235R1 assembly offers Modbus RTU/TCP and Profibus DP communication interfaces for seamless DCS integration. With a rugged DIN-rail mountable form factor (120mm × 80mm × 60mm), 24V DC power input, and operation from -20°C to +60°C, the PPA322B ensures reliable performance in harsh industrial environments, ideal for power generation, petrochemical, chemical, and water treatment applications requiring stable process monitoring and control.

PPA322B HIEE300016R2 HIEE400235R1 (2).png

Key Specifications (PPA322B + HIEE300016R2 + HIEE400235R1)

• Manufacturer: ABB

• Main Model: PPA322B

• Component Assemblies: HIEE300016R2 (Signal Conditioning), HIEE400235R1 (Communication Adapter)

• Product Type: Analog I/O Module (16AI/8AO) for Symphony Plus DCS

• Analog Input (AI): 16 Channels (Isolated 2.5kV AC), 4-20mA DC, 0-10V DC/±5V DC, PT100, K-type Thermocouple

• Analog Output (AO): 8 Channels (Isolated 2.5kV AC), 4-20mA DC/0-10V DC

• Communication Protocols: Modbus RTU (RS-485), Modbus TCP/IP, Profibus DP

• Power Input: 24V DC (Redundant Optional)

• Operating Temperature: -20°C to +60°C

• Mounting: 35mm Standard DIN-Rail

• Protection: IP20, Overvoltage/Overcurrent Protection

• Certifications: CE, UL, IEC 61010-1

2. Core Features (Module + Assemblies)

• HIEE300016R2 Signal Conditioning: 24-bit Sigma-Delta ADC for ±0.05% measurement accuracy; 2.5kV AC isolation prevents cross-interference; supports thermocouple cold junction compensation and RTD linearization.

• HIEE400235R1 Communication Adapter: Dual-protocol compatibility (Modbus/Profibus) enables real-time data exchange with DCS controllers; supports remote parameter configuration and diagnostics.

• High-Precision I/O Processing: 16-bit DAC for AO channels ensures accurate actuator control; channel-to-channel isolation enhances system reliability.

• Redundant Power & Communication: Optional dual 24V DC power inputs and redundant communication ports maximize system availability.

• Advanced Diagnostics: Self-monitoring for open/short circuits, signal drift, and power failures with fault code reporting for quick troubleshooting.

• Easy Configuration: ABB Control Builder Plus software for channel signal type selection and parameter setting.

• Rugged Industrial Design: Vibration-resistant (5g peak) construction for harsh field conditions.

PPA322B HIEE300016R2 HIEE400235R1 (5).png

3. Typical Applications

• Power Generation: Boiler drum level monitoring, steam temperature/pressure control, turbine speed regulation in thermal power plants.

• Petrochemical Industry: Reactor temperature/pressure control, flow measurement, valve position regulation in refineries.

• Water & Wastewater Treatment: Water level monitoring, chemical dosage control, pump speed adjustment.

• Chemical Processing: Batch process control, pH/conductivity measurement, heat exchanger temperature regulation.

• Oil & Gas Production: Wellhead pressure monitoring, pipeline flow control, separator level regulation.

PPA322B HIEE300016R2 HIEE400235R1 (4).png

4. Installation & Maintenance

Installation: Mount on 35mm DIN rail in a ventilated cabinet. Connect 24V DC power, AI/AO field wiring, and communication lines (RS-485/Ethernet). Use ABB Control Builder Plus to configure channel signal types (e.g., thermocouple/RTD for AI, 4-20mA for AO) and communication parameters (Modbus/Profibus). Verify signal isolation and redundancy settings for critical applications.

Maintenance: Inspect terminal connections quarterly for corrosion/looseness; verify communication link integrity monthly. Monitor diagnostic registers via DCS to detect open circuits or signal drift. Update firmware via Ethernet for performance enhancements; store backup parameter sets for quick recovery after module replacement.

Fault Diagnosis: Retrieve fault codes via Modbus/Profibus diagnostic registers (overvoltage, short circuit, communication loss). Check LED indicators (Power: Green, Fault: Red, Communication: Amber) for quick status assessment. Verify channel isolation with a multimeter if signal interference is suspected.

PPA322B HIEE300016R2 HIEE400235R1 (1).png

Technical Document | ABB PPA322B (HIEE300016R2 & HIEE400235R1) | Symphony Plus Analog I/O Module

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.
