3BHE003604R0102 UFC765AE102
Analog Input/Output Module -
Product Description
The 3BHE003604R0102 (model designation: UFC765AE102) is a high-precision analog I/O module developed for ABB's Symphony Plus distributed control system (DCS), specifically designed for industrial process automation applications. This module serves as a critical interface between field sensors/actuators and the central control system, enabling accurate acquisition of analog signals (e.g., temperature, pressure, flow) and precise output of control signals to regulate industrial processes. Engineered with anti-interference and fault-tolerant features, it ensures stable data transmission in harsh industrial environments such as power plants, chemical plants, and oil refineries. This intermediate document specifies the preliminary technical specifications pending final validation and certification.
Technical Parameters
| Parameter Category | Specification |
|---|---|
| Power Supply | 24V DC (±15% tolerance), Power Consumption: 8W (Typical), 12W (Maximum) |
| Analog Input (AI) | 16 Channels | Input Type: 4-20mA (2-wire/4-wire), 0-10V DC | Accuracy: ±0.05% FS | Isolation: 2500V AC (Channel-to-Channel) |
| Analog Output (AO) | 8 Channels | Output Type: 4-20mA (Load ≤ 750Ω), 0-10V DC | Accuracy: ±0.1% FS | Resolution: 16-bit |
| Operating Environment | Temperature: -10°C to +60°C | Humidity: 5% to 95% (non-condensing) | EMC Compliance: IEC 61000-6-2/6-4 |
| Communication | PROFIBUS DP V1 | Transmission Rate: 9.6 kbps to 12 Mbps | Data Update Rate: ≤ 10ms |
| Mechanical Specifications | DIN Rail Mount (35mm) | Dimensions: 240×120×80 mm (L×W×H) | Weight: 0.85 kg |
