TRICONEX Safety Instrumented System (SIS) Modules - Intermediate Documentation
Document Type: Intermediate Technical Reference | Revision: INT-02 | Date: 2025-12-24
For Internal Engineering Review Only | Not for Customer Distribution
Module 4351B
- Type: Communication Module (TRICONEX Trident)
- Function: Modbus TCP/IP & Ethernet/IP communication gateway
- SIL Rating: SIL 3 (IEC 61508/61511)
Compatibility: TRICONEX 3000/4000 Series SIS
Module 3009
- Type: Main Processor Module
- Function: Core controller for TRICONEX 3000 Series SIS
- Redundancy: Triple Modular Redundancy (TMR)
Clock Speed: 200 MHz (industrial-grade processor)
Module 3503E
- Type: Analog Input Module (4-20mA)
- Channels: 16 differential analog inputs
- Accuracy: ±0.05% of full scale
Isolation: Channel-to-channel galvanic isolation (2500V AC)
Module 3511
- Type: Analog Input Module (Thermocouple/RTD)
- Channels: 8 universal analog inputs
- Input Types: J/K/T/E/R/S/B thermocouples, PT100 RTD
Diagnostics: Open/short circuit detection
Module 3721
- Type: Digital Output Module (Form A Relay)
- Channels: 16 non-intrusive relay outputs
- Rating: 250V AC / 30V DC, 5A per channel
Redundancy: TMR-compliant fault-tolerant design
Module 3625A
- Type: Analog Output Module (4-20mA)
- Channels: 8 isolated analog outputs
- Output Range: 4-20mA (loop-powered)
Accuracy: ±0.1% of setpoint
Module 3805H
- Type: Digital Input Module (24V DC)
- Channels: 32 single-ended digital inputs
- Input Voltage: 18-30V DC (sinking/sourcing)
Response Time: < 1ms (programmable)
Module 8312
- Type: Power Supply Module
- Output: 24V DC, 10A (redundant power feed)
- Input: 85-264V AC / 100-300V DC
Certifications: UL 61010-1, ATEX Zone 2
Module 9662-610
- Type: Communication Interface Module
- Protocol: RS-485/RS-422 (Modbus RTU)
- Data Rate: 1200-115200 baud (configurable)
Isolation: 1500V DC between bus and logic
Module 9761-210
- Type: HMI/Operator Interface Module
- Function: Local status monitoring & manual override
- Interface: 24V DC digital I/O + LED indicators
Enclosure: NEMA 4X / IP65 (hazardous area rated)
Module 9563-810
- Type: Remote I/O Communication Module
- Protocol: TRICONEX TriStation Link (TSL)
- Distance: Up to 10km (fiber optic) / 1km (copper)
Redundancy: Dual independent communication paths
Intermediate Document Guidelines
This document is an intermediate technical reference for TRICONEX SIS modules (4351B, 3009, 3503E, 3511, 3721, 3625A, 3805H, 8312, 9662-610, 9761-210, 9563-810) and is not finalized for customer release.
All specifications are based on preliminary engineering data and subject to validation by Schneider Electric (TRICONEX OEM) quality assurance team.
Disclaimer: Unauthorized use or modification of TRICONEX modules may compromise SIL 3 certification and invalidate product warranty. For final datasheets, contact Schneider Electric TRICONEX technical support.
TRICONEX © Schneider Electric 2025 | All Rights Reserved
Document ID: TRX-INT-20251224 | Page 1 of 1
