MTL 8910-PS-DC Instrument System Power Supply
Product Overview
The MTL 8910-PS-DC is a high-reliability, industrial-grade power supply specifically engineered for instrument systems in process automation. It delivers stable DC power to field instruments, controllers, and other critical components, ensuring consistent performance even in harsh industrial environments. Designed with safety and durability in mind, it meets global industrial standards for reliability and operational safety.
Key Features
- Regulated DC output with low ripple and noise for sensitive instrument operation
- Wide input voltage range to accommodate various industrial power sources
- Overload, overvoltage, and short-circuit protection for device and system safety
- High efficiency (up to 90%) reducing energy consumption and heat generation
- LED status indicators for quick monitoring of input power and output status
- Compact, DIN-rail mountable design saving panel space and simplifying installation
Wide operating temperature range (-20°C to +60°C) for extreme environment compatibility
| Parameter | Specifications |
|---|---|
| Input Voltage | 100-240 VAC (50/60 Hz) or 120-370 VDC (dual-input compatible) |
| Output Voltage | 24 VDC ±0.5% (adjustable) |
| Output Current | 10 A (continuous) |
| Ripple & Noise | < 120 mVpp (typical) |
| Efficiency | Up to 90% at full load |
| Dimensions (W×H×D) | 35 mm × 125 mm × 115 mm (DIN-rail mount) |
| Weight | 0.8 kg (net) |
Technical Specifications
Application Areas
Suitable for process automation, oil & gas, chemical, pharmaceutical, and water treatment industries. Powers field instruments, transmitters, PLC modules, and safety systems in both hazardous (Zone 2) and non-hazardous areas.
Compliance & Warranty
CE, UL, CSA, ATEX, IECEx certified. Complies with EN 61010-1 and EN 61326-1 standards. 2-year manufacturer warranty covering defects in materials and workmanship.
MTL 8910-PS-DC Installation Guide Summary
Wiring Diagram Explanation
Terminal Block Configuration (Front Panel):
- Input Terminals (L/N/PE): Connect 100-240 VAC (L=Line, N=Neutral) or 120-370 VDC (L=Positive, N=Negative). PE (Protective Earth) must be grounded for safety.
- Output Terminals (+24V/0V): +24V (positive output) connects to instrument power input; 0V (common ground) connects to instrument ground terminal. Use twisted-pair cables for output wiring.
DC OK Relay Terminals (NO/NC/COM): NO (Normally Open) closes when output is stable; NC (Normally Closed) opens when output is stable. COM (Common) for relay circuit completion (for remote monitoring).
Note: Use 1.5-2.5 mm² copper wires for input/output connections. Torque terminal screws to 0.8-1.0 N·m. Avoid parallel wiring of multiple power supplies unless specified by the manufacturer.
Installation Precautions
Electrical Safety
- Disconnect input power before wiring or maintenance.
- Ensure input voltage matches the module’s rated range (AC/DC not mixed).
- Ground resistance must be ≤ 4 Ω for PE connection.
Mechanical Installation
- Mount on standard 35 mm DIN rail (EN 50022) in a vertical position.
- Leave ≥ 10 mm clearance on all sides for heat dissipation.
- Avoid installation near heat sources or corrosive gases.
Operation & Maintenance
- Check LED indicators after power-on: Green (Power OK) = normal operation.
- Do not exceed maximum output current (10 A) to prevent overload protection triggering.
- Clean the module surface periodically to avoid dust accumulation.
Environmental Requirements
- Operating temperature: -20°C to +60°C (no condensation).
- Relative humidity: 10% to 90% (non-condensing).
- Altitude: ≤ 2000 m above sea level (derate 1% per 100 m above 2000 m).
Quick Troubleshooting
| Symptom | Possible Cause | Solution |
|---|---|---|
| No Power OK LED | Input power missing or incorrect | Check input wiring and voltage; verify PE connection |
| Output voltage unstable | Overload or loose wiring | Reduce load to ≤10 A; re-tighten terminal screws |
| Module overheating | Insufficient clearance or high ambient temperature | Increase ventilation; move module to cooler location |
