GVC736CE101 3BHB045647R0003 Control Board Overview
The GVC736CE101 3BHB045647R0003 is a high-performance control board developed by ABB, specifically designed for integration with ABB’s industrial drives and power electronics systems. As a key component in motor control and power conversion applications, it provides precise signal processing, communication, and control logic execution to ensure stable operation of drives in demanding industrial environments.
Engineered with advanced microprocessor technology and robust circuit design, the board offers seamless compatibility with ABB’s ACS880 and other drive series. It combines real-time data processing capabilities, multiple communication interfaces, and comprehensive diagnostic functions, making it suitable for applications requiring high-precision motor control, speed regulation, and system synchronization.
Core Features & Technical Advantages
- High-Performance Processing: Equipped with a 32-bit RISC microprocessor with high clock speed, enabling fast execution of control algorithms and real-time response to system commands.
- Multi-Protocol Communication: Supports industrial communication protocols including Profibus DP, Modbus RTU/TCP, and Ethernet/IP, facilitating seamless integration with PLCs, SCADA systems, and industrial networks.
- Advanced Motor Control: Implements vector control, scalar control, and torque control algorithms, supporting precise speed and torque regulation for asynchronous and synchronous motors.
- Comprehensive I/O Interface: Provides analog inputs (4-20mA, 0-10V), digital inputs/outputs, and pulse-width modulation (PWM) signals for flexible connection with sensors, actuators, and external control devices.
- Enhanced Diagnostic Functions: Real-time monitoring of voltage, current, temperature, and fault status, with detailed error logging and alarm outputs for quick troubleshooting.
- Rugged Design: Industrial-grade components and conformal coating protection against dust, moisture, and vibration, ensuring reliable operation in harsh factory environments.
- Configuration Flexibility: Supports parameter configuration via ABB Drive composer software, allowing customization of control logic and operating parameters for specific application requirements.
Safety Compliance: Integrates safety functions (SIL 2) including safe torque off (STO), meeting international safety standards for industrial machinery and drive systems.
Key Technical Specifications
| Specification Category | Details | Remarks |
|---|---|---|
| Model Information | GVC736CE101 / 3BHB045647R0003 | ABB control board for industrial drives |
| Processor & Memory | 32-bit RISC microprocessor, 500MHz Flash Memory: 8MB RAM: 256MB DDR3 | High-speed data processing and storage |
| Communication Interfaces | Ethernet: 10/100BASE-TX (2 ports) Profibus DP: RS-485 Modbus RTU: RS-485 USB: 1 port (configuration) | Multi-protocol support for system integration |
| I/O Interfaces | Analog Inputs: 4 channels (4-20mA/0-10V) Digital Inputs: 8 channels (24VDC) Digital Outputs: 4 channels (24VDC, 0.5A) PWM Output: 2 channels | Flexible connection with external devices |
| Environmental Ratings | Operating Temp: -10°C to 60°C Humidity: 5-95% (non-condensing) Vibration Resistance: IEC 60068-2-6 | Suitable for harsh industrial environments |
| Power Requirements | Operating Voltage: 24VDC ±10% Power Consumption: ≤15W | Compatible with standard industrial power supplies |
| Physical Dimensions | 220mm × 160mm × 30mm (L×W×H) Weight: Approx. 0.3kg | Compact design for drive cabinet installation |
| Certifications | UL, CE, IEC 61800, SIL 2, RoHS | Compliant with global industrial and safety standards |
Application Scenarios & YMGK Purchase Support
Target Industries & Use Cases
The GVC736CE101 3BHB045647R0003 control board is widely applied in industries requiring precise motor control and drive systems, including:
Industrial Drives & Motors
Variable frequency drives (VFDs), servo drive systems, high-power motor control cabinets
Manufacturing & Machinery
Conveyor systems, pumps, fans, compressors, and material handling equipment
Metallurgy & Mining
Rolling mill drives, crusher control, mining machinery speed regulation systems
Energy & Utilities
Wind turbine pitch control, water pump drives, power plant auxiliary equipment
YMGK Procurement Services
- Global 121 shared inventories, direct procurement from overseas warehouses for fast delivery
- 100% brand new and original ABB GVC736CE101 3BHB045647R0003 boards with one-year warranty
- Volume discounts available for multi-unit orders; price matching with other suppliers
- Professional technical support for board configuration, integration, and troubleshooting
- 24/7 customer service to address procurement and after-sales inquiries
All product names, trademarks, brands, and logos used are the property of their respective owners. Descriptions are for identification purposes only and do not imply affiliation or authorization from any rights holder.
