5SHY3545L0016 3BHB020720R0002 IGCT Module Overview
The 5SHY3545L0016 3BHB020720R0002 is a high-power Insulated Gate Bipolar Transistor (IGCT) module developed by ABB, designed for demanding industrial power conversion and control applications. As a core component in power electronics systems, it integrates advanced IGBT chips and freewheeling diodes, delivering exceptional switching performance, high efficiency, and robust reliability to meet the requirements of medium-voltage drives, inverters, and power supplies.
Engineered with ABB’s proprietary semiconductor technology, the module combines high current handling capacity, low on-state voltage drop, and excellent thermal management. It complies with international industrial standards, making it suitable for integration into renewable energy systems, industrial drives, traction systems, and other high-power applications where stable and efficient power conversion is critical.
Core Features & Technical Advantages
- High Power Density: Rated current of 450A and voltage of 1700V, offering excellent power-to-volume ratio for compact system design in high-power applications.
- Advanced IGBT Technology: Adopts ABB’s latest generation IGBT chips with low on-state loss (VCE(sat)) and fast switching speed, improving overall system efficiency and reducing energy consumption.
- Integrated Freewheeling Diodes: Built-in ultra-fast recovery diodes (FRDs) with low reverse recovery loss, enhancing switching reliability and suppressing voltage spikes.
- Robust Thermal Performance: Aluminum nitride (AlN) substrate with high thermal conductivity ensures efficient heat dissipation, extending the module’s operational lifespan even under high-load conditions.
- Enhanced Protection Mechanisms: Equipped with over-temperature, over-current, and short-circuit protection capabilities, safeguarding the module and connected components from damage.
- Standard Package Design: Complies with industry-standard 6-pack module dimensions, enabling easy replacement and compatibility with existing ABB and third-party power electronic systems.
- High Reliability: Undergoes rigorous quality testing and aging validation, ensuring stable performance in harsh industrial environments with temperature variations and electrical stress.
Low Electromagnetic Interference (EMI): Optimized switching characteristics minimize EMI emissions, reducing the need for additional filtering components and simplifying system compliance with EMC standards.
Key Technical Specifications
| Specification Category | Details | Remarks |
|---|---|---|
| Model Information | 5SHY3545L0016 / 3BHB020720R0002 | ABB high-power IGBT module (6-pack configuration) |
| Electrical Ratings | Collector-Emitter Voltage (VCE): 1700V Collector Current (IC): 450A (at 25°C) Peak Collector Current (ICM): 900A | High voltage and current handling capacity |
| Thermal & Switching Parameters | On-state Voltage (VCE(sat)): ≤2.2V (at IC=450A) Switching Frequency: Up to 10kHz Junction Temperature Range (TJ): -40°C to 150°C | Low loss and wide operating temperature range |
| Package & Thermal Design | Package Type: Standard 6-pack (Pressfit) Substrate Material: Aluminum Nitride (AlN) Thermal Resistance (Rth(j-c)): ≤0.15 K/W | Efficient heat dissipation and standard compatibility |
| Protection Features | Over-temperature protection (OT) Over-current protection (OC) Short-circuit protection (SC) Anti-parallel freewheeling diodes | Comprehensive safeguards for system reliability |
| Physical Dimensions | Length × Width × Height: 190mm × 140mm × 40mm Weight: Approx. 1.8kg | Compact design for space-constrained installations |
| Certifications | UL, CE, RoHS, IEC 60747 | Compliant with global industrial and environmental standards |
Application Scenarios & YMGK Purchase Support
Target Industries & Use Cases
The 5SHY3545L0016 3BHB020720R0002 IGBT module is widely applied in high-power industrial applications, including:
Industrial Drives
Medium-voltage variable frequency drives (VFDs), motor control centers, heavy-duty industrial motor drives
Renewable Energy
Wind turbine converters, solar inverter systems, energy storage system (ESS) power conversion
Traction Systems
Railway traction converters, electric vehicle (EV) powertrains, marine propulsion systems
Power Supplies & Converters
Uninterruptible Power Supplies (UPS), medium-voltage rectifiers, DC-DC converters
YMGK Procurement Services
- Global 121 shared inventories, direct procurement from overseas warehouses for fast delivery
- 100% brand new and original ABB 5SHY3545L0016 3BHB020720R0002 modules with one-year warranty
- Volume discounts available for bulk orders; price matching with other suppliers
- Professional technical support for module selection, compatibility verification, and application guidance
- 24/7 customer service to address procurement and after-sales inquiries
All product names, trademarks, brands, and logos used are the property of their respective owners. Descriptions are for identification purposes only and do not imply affiliation or authorization from any rights holder.
