The ABB CI532V01 (3BSE003826R1) is a specialized RCOM Interface Submodule designed for ABB's industrial control systems. This module is essential for enabling communication within these complex automation environments, typically within the Advant OCS (Open Control System) with Master software, particularly with controllers like the Advant Controller 450.

Product Description

The CI532V01 is a two-channel RCOM (Remote Communication) interface submodule. Its primary function is to facilitate communication between different parts of a distributed control system or to connect the control system to other devices and networks. RCOM interfaces are crucial for data exchange, command transmission, and status monitoring across various industrial processes.

This module is designed to integrate seamlessly into ABB's modular control system racks, acting as a bridge for data flow. Its two independent channels offer flexibility in connecting to multiple communication lines or providing redundancy for critical links. As a "submodule," it implies it fits into a larger carrier board or backplane, which then connects to the main controller. It's built for the demanding conditions of industrial environments, ensuring reliable and robust communication.

Product Specifications

• Model Name: CI532V01
• ABB Part Number: 3BSE003826R1
• Product Type: RCOM Interface Submodule
• Channels: 2 independent communication channels.
• Compatibility: Primarily designed for use with ABB Advant OCS (Open Control System) with Master software, including controllers like the Advant Controller 450.
• Functionality: Enables remote communication and data exchange within a distributed control system.
• Interface Type: RCOM (Remote Communication). The exact physical layer and protocol might vary but typically supports industrial communication standards for robust data transfer.
• Modularity: Designed as a plug-in submodule for easy integration into ABB control system racks.

Product Application Cases

The ABB CI532V01 (3BSE003826R1) is vital in large-scale industrial automation applications where reliable and extensive communication networks are necessary. Its use cases primarily revolve around connecting and coordinating various components within a DCS environment.

• Process Control in Large Plants: In industries like power generation, oil and gas, chemical, and pulp & paper, the CI532V01 is used to establish communication links between controllers, remote I/O units, human-machine interfaces (HMIs), and other intelligent devices spread across a large plant. This ensures real-time data flow for monitoring, control, and optimization of complex processes.
• Distributed Control Systems (DCS): As a core component for Advant OCS, it plays a key role in the architecture of DCS, allowing for the distributed execution of control functions while maintaining centralized supervision. This is critical for managing vast numbers of sensors and actuators over wide areas.
• Remote Monitoring and Control: The module enables communication with geographically dispersed equipment or substations, allowing operators to monitor and control processes from a central control room. This is particularly useful for pipelines, power transmission grids, and distributed manufacturing sites.
• Integration of Subsystems: It facilitates the integration of different subsystems or third-party devices into the main ABB control system, ensuring interoperability and a unified control environment. This could include connecting to legacy systems or specialized equipment that uses a different communication protocol, with the RCOM module acting as an interface translator or gateway.
• Data Acquisition and Alarming: By enabling robust communication, the CI532V01 supports the efficient collection of process data for analysis and historical trending, as well as the rapid transmission of alarm signals in case of deviations or faults.

Click to download the relevant instruction manual

3BSE003826R1.pdf
