Product Number:ABB 3ASC25H204 Processor module

Product Overview

ABB 3ASC25H204 is a control module applied in the field of industrial automation. The following is the detailed information about it:

Product Overview:

It is a high-power PLC module, suitable for industrial automation systems.

It belongs to the DAPC 100 series and is mainly used in ABB frequency converters, especially the DARA series frequency converters, functioning as a control board.

It originated in Sweden.

Functional features:

Precise control: Designed to provide precise control for a wide range of industrial applications.

High reliability: Compact design, low power consumption, and high operational reliability. With a solid structure and high-quality materials, it can ensure durability in harsh industrial environments and is suitable for continuous operation under harsh conditions.

Strong communication capability: Equipped with advanced communication protocols, it can be seamlessly integrated with various automation systems, facilitating data exchange and control operations.

User-friendly: It features a user-friendly interface, simplifying the programming and setup process. Technicians and engineers can efficiently configure the system according to specific requirements without extensive training.

Technical parameters:

Working voltage: Usually 220V or 230V AC.

Communication interface: Supports multiple communication protocols, such as RS485, Modbus RTU, DeviceNet, Canopen, etc.

Processing speed: Up to 1MHz.

Programming language: Supports IEC 61131-3 programming language.

Memory capacity: 256KB user memory.

Dimensions: Approximately 75mm×100mm×120mm.

Weight: 0.34kg.

Operating temperature: -20℃ to + 55℃ or + 60℃.

Humidity range: 5% to 95%, no condensation.

Application field:

Relay protection system: It protects electrical equipment such as transformers, generators and motors when electrical faults (such as overcurrent, short circuit, etc.) occur.

Automation and control systems: In industrial automation applications, they are used to control electrical loads and systems.

Monitoring and diagnostic system: It provides real-time monitoring, data recording and diagnostic functions to prevent equipment damage and minimize downtime to the greatest extent.

Switchgear and substation equipment: As protective relays within switchgear in high-voltage substations or other industrial electrical infrastructure.

ABB 3ASC25H204 Processor module

This article is originally written by KIMI Xiaoming. Please bring the link www.xbplcdcs.com when reprinting

Client Concern

Part Number : ABB 3ASC25H204 Processor module

Manufacture : ABB

Condition : Brand New with 12 month warranty

Lead Time : in stock

Status: 100% original

Payment method: T/T. Currencies for receipt: US dollar, New Zealand dollar, Chinese yuan, euro, Hong Kong dollar, Australian dollar, British pound, Canadian dollar, ruble and other global currencies

Sales Manager: Li Ming

WeChat: 18059884790

WHATSAPP:+86 18059884790

Click to add 【WHATSAPP】 and start a new experience of instant communication

Email:plc66@qq.com

ABB 3ASC25H204 Processor module  Not what you want?

For more product information about Bently Nevada, please click on (YMGK)

Hot Module

The models related to ABB CP800 Communication Processor Module of HPC800 may be as follows:

CP800A: Judging from some materials, it might be a related derivative model or an improved model of CP800. For example, it is mentioned that CP800A provides PN800 factory network communication for HPC800A with conformal coating. In terms of dimensions, the net depth/length is 243.84mm, the net height is 73.66mm, the product width is 170.18mm, and the net weight of the product is 0.449kg.

HPC800K02 This is a model in the HPC800 series. Among the mentioned HPC800 controller kit (redundancy), it includes 2x (HC800, CP800, MB810), 1x (CTB810, CTB811), and 4x (TER8x0). Here, CP800 exists as the communication processor module in the HPC800K02 suite.

In addition, the AC 800M series is somewhat related to the HPC800 and CP800. CP800 belongs to the ABB AC 800M series. The AC 800M is a rail-mounted module series, consisting of a CPU, communication module, power supply module and various accessories. Although the AC 800M series is not completely equivalent to the HPC800, the CP800 plays an important role in communication processing among them and provides support for the communication functions of the entire system
