Product Number:ABB EL3020  19-inch rack-mounted continuous gas analyzer

Product Overview

The ABB EL3020 is a 19-inch rack-mounted continuous gas analyzer and belongs to the ABB EasyLine series. The following is its detailed introduction:

Characteristics

Diverse measurement components: Up to five measurement components can be supported.

Automatic calibration: Equipped with an automatic calibration function, including pump and valve control, simplified calibration can be carried out using air or an internal calibration cell.

Rich communication interfaces: It provides communication interfaces such as Modbus, Profibus, and Ethernet, facilitating communication with external systems.

Friendly operation interface: Menu-driven operation interface with clear text status messages, easy to operate.

Multiple optional functions: It can be equipped with an optional built-in gas supply system and also provide explosion-proof certification, suitable for hazardous locations. In addition, the QAL3 monitoring function can be optionally equipped for storing and analyzing equipment adjustment data.

Technical parameters

Ambient temperature: The operating temperature is + 5℃ to + 45℃ (+ 5℃ to + 40℃ when URAS 26 is used together with other analyzers), and the storage and transportation temperature is -25 ℃ to + 65℃.

Relative humidity: less than 75%, slight condensation is allowed.

Power supply: Input voltage 100-240V AC ±15% / +10%, 50-60Hz ±3Hz, maximum power consumption 187VA.

Dimensions and weight: 19-inch rack-mounted housing, 3 units in height, weighing approximately 7 to 15 kilograms.

Gas connection: The inlet/outlet of the sample gas can use FPM hoses (stainless steel 1.4305/SAE 303 threaded joints with 4mm inner diameter hoses) or PTFE or stainless steel tubes (1/8 NPT inner thread). The built-in gas supply system connects the sample gas inlet and outlet in the factory and requires specific configuration.

Display: Backlit graphic display screen with a resolution of 240x160 pixels, capable of simultaneously showing numerical values (with physical units) and bar charts, up to 5 values can be displayed simultaneously. Status display is indicated by symbols on the display screen, and activity status messages can be directly accessed from the measurement value display.

Operation: Menu-assisted operations are carried out through five keys (the cursor cross key and the confirm key). Rarely used functions can be set through the configuration software ECT.

Measurement range switching: Supports manual, automatic (automatic range) or external control through digital input, and feedback through digital output, regardless of the selected measurement range switching type.

Application scenarios

Industrial process control: Monitoring the oxygen concentration during the combustion process, the concentration of harmful gases in the emitted gases, etc.

Environmental monitoring: Monitoring flue gas emissions, vehicle exhaust, and environmental air quality, etc.

Scientific research: For research and development work in laboratories.

Energy industry: Applicable to gas monitoring of equipment such as power plants, boilers, and burners.

Chemical industry: It can be used for gas analysis in the chemical production process, waste gas treatment and other links.

Metallurgical industry: It is used for gas composition monitoring in processes such as blast furnaces and converters.

Food and beverage industry: It can be used for packaging gas detection, fermentation process monitoring, etc.

ABB EL3020  19-inch rack-mounted continuous gas analyzer

ABB EL3020.pdf

This article is originally written by KIMI Xiaoming. Please bring the link www.xbplcdcs.com when reprinting

Client Concern

Part Number : ABB EL3020  19-inch rack-mounted continuous gas analyzer

Condition : Brand New with 12 month warranty

Lead Time : in stock

Status: 100% original

Payment method: T/T. Currencies for receipt: US dollar, New Zealand dollar, Chinese yuan, euro, Hong Kong dollar, Australian dollar, British pound, Canadian dollar, ruble and other global currencies

Sales Manager: Li Ming

WeChat: 18059884790

WHATSAPP:+86 18059884790

Click to add 【WHATSAPP】 and start a new experience of instant communication

Email:plc66@qq.com

ABB EL3020  19-inch rack-mounted continuous gas analyzer  Not what you want?

Hot Module

The models related to ABB EL3020 include EL3040, and they both belong to the ABB EasyLine series. The following are some differences between the two:

Application scenario: EL3020 is suitable for measuring flammable gases in non-explosive environments. EL3040 is equipped with an explosion-proof device and meets the explosion-proof requirements of II 3G. It can measure non-flammable gases and vapors in hazardous areas.

The exterior dimensions of the EL3020 are 19-inch rack-mounted chassis with a height of 3HU. The height of the Magnos27 EL3040 is 4HU.

In addition, the EL3020 can be equipped with a variety of measurement modules, such as the Uras26 infrared photometer, Magnos206 oxygen analyzer, Caldos27 thermal conductivity analyzer, etc., to achieve the measurement of different gas components
