Controllers - AC 800M Controllers PM857K02
Time:2025-05-08 15:54:29   View count:

Product Number:Controllers - AC 800M Controllers PM857K02


Product Overview


The CPU board contains the microprocessor and RAM memory, a real-time clock, LED indicators, INIT push button, and a CompactFlash interface.

The base plate of the PM857 controller has two RJ45 Ethernet ports (CN1, CN2) for connection to the Control Network, and two RJ45 serial ports (COM3, COM4). One of the serial ports (COM3) is an RS-232C port with modem control signals, whereas the other port (COM4) is isolated and used for the connection of a configuration tool. The controller supports CPU redundancy for higher availability (CPU, CEX-Bus, communication interfaces and S800 I/O).

The high integrity functionality is enabled by the addition of an SM812 module and the SIL-certified software. This enables non-critical control schemes to be upgraded to SIL-certified schemes by the addition of a plug-in SM81x module, plus a selection of the appropriate software. The AC 800M High-Integrity also offers IEC 61508 and TÜV-certified control environment for combining safety and business-critical process control in one controller unit without sacrificing the safety integrity.

The PM857 can handle Max 128 I/O signals. Certified for SIL3. Requires configuration according to Safety Manual.

Package including:
2 pcs PM857K01, Safety Processor unit
1 pcs TK850, CEX-bus expansion cable
1 pcs TK851, RCU-Link cable

Features and benefits

  • ISA Secure certified - Read more
  • AC 800M High up to SIL 3 certified using PM857/SM812, PM863/SM812, PM865/SM811 or PM867/SM812
  • Supports S800 I/O High Integrity (PM857, PM863, PM865, PM866A and PM891)
  • The controller can be configured with 800xA control builder
  • The controller has full EMC certification
  • TÜV Certified SIL 2 and SIL 3
  • Built-in redundant Ethernet Communication ports








      Controllers - AC 800M Controllers PM857K02





      Controllers - AC 800M Controllers PM857K02



      Sales Manager: Li Ming

      WeChat: 18059884790

      WHATSAPP:+86 18059884790

      Email:plc66@qq.com



      Express delivery is provided

      Product Number:Controllers - AC 800M Controllers PM857K02

      Status: 100% original

      Warranty period: 12 months.

      Payment method: T/T. RMB (CNY) is supported.





      For more product videos, please click to view




      Controllers - AC 800M Controllers PM857K02  Not what you want?


      Name
      High Integrity
      Memory
      Performance
      Redundancy
      No
      12 MB (from 800xA 5.1 FP4)
      0.46 ms
      No
      No
      16 MB (from 800xA 5.1 FP4)
      0.46 ms
      No
      Yes
      32 MB
      0.17 ms
      No
      Yes
      32 MB
      0.17 ms
      Yes
      No
      16 MB
      0.36 ms
      No
      No
      16 MB
      0.36 ms
      Yes
      No
      16 MB (from 800xA 5.1 FP4)
      0.23 ms
      No
      No
      32 MB
      0.18 ms
      No
      No
      32 MB
      0.18 ms
      Yes
      Yes
      32 MB
      0.17 ms
      No
      Yes
      32 MB
      0.17 ms
      Yes
      No
      64 MB
      0.09 ms
      No
      No
      64 MB
      0.09 ms
      Yes
      Yes
      64 MB
      0.09 ms
      No
      Yes
      64 MB
      0.09 ms
      Yes
      No
      256 MB
      0.043 ms
      No
      No
      256 MB
      0.043 ms
      Yes
      Yes
      -
      Hot swap supported
      Yes
      No
      -
      Hot swap supported
      Yes
