Triconex 3603T 120VDC TMR Digital Output Module

Product Description

The Triconex 3603T is a triple modular redundant (TMR) 16-channel digital output module for the Tricon SIS safety instrumented system. It is a 120 VDC opto-isolated commoned DO module, used to drive field solenoid valves, relays and alarm devices in safety-critical ESD, fire & gas protection systems. It adopts TMR voting architecture with continuous on-board diagnostics, certified for IEC 61508 SIL3 safety applications.

Features

• 16 opto-isolated digital output channels, rated 90–150 VDC nominal 120 VDC
• TMR triple modular redundancy voting circuit, single fault tolerant design
• Per-channel continuous diagnostics, load and fuse fault detection, stuck-on detection
• Hot-swappable in Tricon rack, backplane bus communication with Tricon main controller
• Status LED indicators for module health, run, fault and channel alarm
• SIL3 certified for safety instrumented system applications
• Commoned output type, matched with termination assemblies like 9664-810
• Industrial EMC and wide temperature design for refinery, oil & gas and power plant cabinets

Application Scenarios

• Oil & gas, refinery and chemical plant ESD emergency shutdown system
• Fire and gas (F&G) safety protection system solenoid drive and alarm output
• Power plant boiler, turbine safety interlock and trip control
• Tricon SIS rack expansion, spare parts replacement and safety system retrofit
• Offshore platform critical safety instrumented control circuits

FAQ

Q: What is the difference between 3603B, 3603E and 3603T?
A: 3603B is non-commoned; 3603E and 3603T are commoned 120VDC DO variants for Tricon SIS.

Q: Which system does 3603T belong to?
A: It belongs to Schneider Triconex Tricon SIS safety instrumented control platform.

Q: What is the safety level?
A: IEC 61508 SIL3 certified for safety critical loop control.

Q: Is this module still in production?
A: Legacy Tricon TMR I/O series is discontinued; stock is mainly surplus, tested refurbished spare parts.
