ABB 560AIR01 1KGT036500R0001 8-Channel Analog Input Module for RTU560

Product Description

The 560AIR01 (1KGT036500R0001) is an 8-channel analog input module for the ABB RTU560 substation remote terminal unit (now Hitachi Energy RTU560 platform). It collects analog current and voltage signals from field transmitters and converts them into digital AMI/MFI measurement data for substation control, monitoring and SCADA communication. It is widely used in power grid substation automation, feeder monitoring and power plant auxiliary RTU systems.

Features

• 8 independent analog input channels, 16-bit AD converter resolution
• Supported measurement ranges: ±2mA, ±5mA, ±10mA, ±20mA, ±40mA, ±2VDC, 0–20VDC
• Supports AMI analog measured values and MFI floating point measured information
• Galvanic channel isolation, built-in signal filtering and overvoltage protection
• Rack slot mounting, backplane bus communication with RTU560 main CPU unit
• On-board LED indicators for power, run status and channel fault diagnosis
• Compact rail/rack design, low power consumption, net weight approx 0.125kg
• Time-stamped data acquisition, suitable for IEC 60870-5-101/104 SCADA protocol

Application Scenarios

• Transmission and distribution substation automation RTU560 system
• Voltage, current, power, temperature and pressure transmitter signal acquisition
• SCADA remote monitoring for power grid, wind farm and solar power stations
• Industrial power plant auxiliary control and electrical parameter monitoring
• RTU560 rack expansion, spare parts replacement and system retrofit

FAQ

Q: Which system does 560AIR01 belong to?
A: It is an I/O module for ABB/Hitachi Energy RTU560 remote terminal unit.

Q: What is the difference between 560AIR01 and 560AIR02?
A: 560AIR01 supports both current and 0–20V voltage signals; 560AIR02 only supports current input ranges.

Q: What is the part number 1KGT036500R0001?
A: It is the full order code for 560AIR01 R0001 version.

Q: Is this module still available?
A: RTU560 series is maintained by Hitachi Energy; original spare stock and tested refurbished modules are available.
