COBO Deutschland TERA12 12-inch Rugged Programmable Display Terminal

Product Description

TERA12 is a 12.1-inch rugged programmable HMI display terminal developed by COBO Deutschland GmbH, designed for heavy-duty off-highway mobile machinery. It features 1280×800 TFT sunlight-readable screen, available versions with capacitive multi-touch or physical push-button keypad. Powered by i.MX6 processor with 1GB RAM and 8GB flash memory, this robust cabin terminal supports ISOBUS AEF certification, dual CAN bus, BroadR-Reach Ethernet, RS232 and multi-channel camera input. The housing is shock and vibration resistant, wide operating temperature range, built with RTC real-time clock, buzzer and internal IMU accelerometer/gyroscope. It supports programming via VT3, QT/QML for custom dashboard, machine monitoring and control UI. TERA12 includes in-dash and out-dash mounting variants, widely deployed as operator cabin display for construction, agricultural and lifting equipment. Spare units include new surplus and fully tested refurbished terminals.

Key Functions

• 12.1" 1280×800 sunlight visible TFT display, optional glove-compatible capacitive multi-touch or hard push buttons
• Custom dashboard visualization, real-time machine data monitoring, alarm and fault status display
• Multi-camera video input for rear view and working area surveillance
• Dual CAN bus, BroadR-Reach, RS232 communication interfaces; AEF ISOBUS certified for agricultural machinery
• Programmable with VT3 and QT/QML, supports custom graphic interface and machine control logic
• Onboard RTC, buzzer, accelerometer & gyroscope for tilt, vibration and event detection
• Wide temperature, shock and vibration rugged construction for heavy mobile vehicle cabin environment
• Wake-up triggers via power supply, CAN message or ignition signal for vehicle power management

Application Scenarios

• Construction machinery: mobile crane, aerial work platform, excavator cabin operator terminals
• Agriculture equipment: tractor, harvester, precision seeder ISOBUS cabin display
• Material handling: telehandler, forklift and heavy lifting machinery monitoring system
• Special off-highway vehicles, forestry machines and industrial mobile equipment
• Spare replacement and cabin HMI retrofit for existing COBO TERA12 installed machines

FAQ

Q1: What are the two mounting types of TERA12?
A1: In-dash flush mounting and out-dash bracket mounting versions, available in touchscreen or physical button configurations.

Q2: What programming tools are supported?
A2: VT3 and QT/QML, users can build custom graphical dashboards and machine control interfaces.

Q3: Does TERA12 support ISOBUS?
A3: Yes, it holds AEF ISOBUS certification for agricultural tractor and implement communication.

Q4: Common failure symptoms?
A4: Touchscreen unresponsive, CAN communication dropout, screen backlight failure, boot loop, camera input loss, RTC clock drift.
