Johnson Controls MS-NAE5510-702 Metasys Network Automation Engine

Product Brief Description

The Johnson Controls MS-NAE5510-702 is a Metasys NAE55 series network automation engine for building management and HVAC automation systems. Powered by Intel Atom processor, this DIN-rail mounted controller acts as a core network supervisor, supporting BACnet MS/TP and Ethernet communication. It executes global control logic, collects device data, manages alarms and historical trending for field controllers. With 24VAC power supply, built-in real-time clock and backup battery for data retention, it integrates Metasys field devices and third-party BACnet equipment for medium and large building automation projects.

Product Functions

• Run global building automation control strategies, schedule programs and interlock logic for HVAC, lighting and mechanical equipment
• Support dual BACnet MS/TP field buses and Ethernet port to communicate with Metasys field controllers and BACnet compatible devices
• Real-time alarm management, event logging, historical data trending and automatic alarm notification via email
• Embedded web server allows remote monitoring, status check and configuration access through web browsers
• Onboard backup battery preserves real-time clock and critical configuration data during power outages
• Seamlessly connect to Metasys application and data server for centralized building system visualization and reporting

Application Scenarios

• Commercial office building HVAC and building management automation
• Hospital, university campus and large shopping mall Metasys BAS systems
• Data center facility monitoring, cooling and mechanical equipment supervision
• Hotel, airport and public facility energy management and environmental control
• Retrofit and upgrade projects for legacy Johnson Controls Metasys building automation networks
