TRICONEX 3902X Universal I/O Interface Terminal Board-KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

TRICONEX 3902X Universal I/O Interface Terminal Board

Tricon CX Safety System I/O Interface for Intrinsically Safe & General-Purpose Field Devices

1. Product Overview

The TRICONEX 3902X is a Universal I/O (UIO) Interface Terminal Board designed exclusively for the EcoStruxure™ Tricon CX Safety Instrumented System (SIS), providing a flexible 16-channel interface for connecting intrinsically safe and general-purpose field devices to Tricon CX I/O modules. As a critical component in SIL 3 (IEC 61508) compliant systems, it supports seamless integration with a wide range of AI, DI, AO, DO, and temperature modules, enabling customizable I/O configurations for diverse industrial applications. Featuring robust galvanic isolation, real-time diagnostic monitoring, and compatibility with GMI terminal blocks (TB-D5016-TRI-010), the 3902X ensures reliable signal transmission, simplified field wiring, and enhanced system safety in harsh environments such as oil & gas, petrochemical, and power generation facilities. Its hot-swappable design and compliance with global safety certifications (TÜV, CE, UL) minimize maintenance downtime while meeting the highest safety standards for critical safety loops.

TRICONEX 3902X (3).png

2. Key Specifications

• Module Type: Universal I/O Interface Terminal Board (Tricon CX Exclusive)

• Channel Capacity: 16 Configurable I/O Channels

• Compatible I/O Modules: AI (D5014S, D5015SK, D5016SK), DI (D5031S, D5032S, D5037S), AO (D5020S), DO (D5049S), Temperature (D5072S-099)

• Terminal Block Compatibility: GMI Terminal Block (TB-D5016-TRI-010, 16 Slots)

• Isolation: 2500V AC Galvanic Isolation (Field-to-Bus, Channel-to-Channel)

• Diagnostics: Real-Time Channel Status Monitoring, Module Fault Detection, Wiring Integrity Checks

• Power Requirements: Powered via Tricon CX I/O Backplane (No External Power Needed)

• Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C

• Mechanical: Hot-Swappable, Rack-Mount; Dimensions: 140mm×99mm×64mm; Weight: 0.45kg

• Safety Certifications: SIL 3 (IEC 61508), TÜV Approved, CE Marked, UL Listed

• Field Wiring: Supports Single-Ended/Differential Configurations, Intrinsically Safe (IS) Barrier Compatibility

TRICONEX 3902X (2).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders

3. Core Features & Benefits

• 16-Channel Flexibility: Customizable I/O configurations for mixed signal types (AI/DI/AO/DO/temperature)

• Intrinsically Safe Compatibility: Direct connection to IS field devices with certified GMI terminal blocks

• Robust Isolation: 2500V AC galvanic isolation protects against electrical surges and cross-channel interference

• Real-Time Diagnostics: Proactive fault detection enables predictive maintenance and reduces unplanned downtime

• Hot-Swappable Design: Module replacement without system shutdown minimizes operational disruptions

• SIL 3 Compliance: Meets the highest safety integrity level for critical SIS applications

• Seamless Tricon CX Integration: Plug-and-play compatibility with Tricon CX I/O modules simplifies system design and deployment

TRICONEX 3902X (1).png

4. Typical Applications

• Oil & Gas: ESD system field device connectivity, pipeline monitoring sensor interfaces, offshore platform safety loops

• Petrochemical: Reactor temperature/pressure monitoring, burner management system I/O, toxic gas detector connections

• Power Generation: Turbine protection system I/O, boiler safety interlocks, switchgear control interfaces

• Chemical Processing: Batch process control I/O, pressure relief valve actuation, HMI field data acquisition

• General Industry: Critical machine safety system I/O, fire & gas detection system integration, emergency shutdown interfaces

5. Compatibility & Model Comparison

Compatible Controllers: EcoStruxure™ Tricon CX Safety System

Related Modules:

- 3902AX: 3902X variant with HART communication support for smart field devices

- 3902X: Standard UIO interface terminal board (This Model, No HART)

Technical Documentation | TRICONEX 3902X | Universal I/O Interface Terminal Board
