GE Multilin 369-HI-R-M-0-0-0-E Motor Management Relay
Comprehensive Protection, Monitoring & Diagnostics for Medium & High Voltage Motors
1. Product Overview

The GE Multilin 369-HI-R-M-0-0-0-E is an advanced motor management relay designed for comprehensive protection, monitoring, control, and diagnostics of medium and high-voltage three-phase induction or synchronous motors. It integrates 12 RTD temperature monitoring, enhanced metering, and advanced diagnostic functions, providing protection against overload, jam, stall, ground fault, unbalance, and RTD overtemperature. The relay features event recording, oscillography, and motor health reports, supporting predictive maintenance to extend motor lifespan. With high-voltage control power input and flexible communication options, it is widely used in power generation, oil & gas, metallurgy, and chemical industries, ensuring reliable operation of critical motor assets and minimizing production downtime.


369-HI-R-M-0-0-0-E -2.png


2. Key Technical Specifications
• Brand & Model: GE Multilin 369-HI-R-M-0-0-0-E
• Product Type: Advanced Motor Management Relay
• Core Function: Motor Protection, Control, Monitoring, Diagnostics, Event Recording
• Control Power: 50-300 VDC, 60-265 VAC, 50/60 Hz
• Protection Functions: Overload (Inverse Time), Jam, Stall, Ground Fault, Current Unbalance, Undercurrent, RTD Overtemperature, Voltage Unbalance, Under/Overvoltage
• RTD Inputs: 12 Channels (PT100/PT1000, Ni100/Ni120, Cu10 Compatible)
• Digital Inputs: 6 Optically Isolated (Dry Contact)
• Outputs: 2 Form C Electromechanical Relays (Trip/Alarm), Optional 2 Form A Solid-State Relays
• Metering Parameters: Current, Voltage, Power (kW/kVA/kvar), Energy (kWh/MWh), Frequency, Power Factor, Thermal Capacity Usage
• Event Recording: 512 Events with Timestamps; 3 Waveform Records per Trip (16 Cycles Each)
• Communication: Modbus RTU (RS485), Optional Profibus DP, DNP3.0
• Display: Enhanced Faceplate with Graphical Diagnostics
• Software: Enervista 369 Setup Software for Configuration & Monitoring
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Dimensions (W×H×D): 144 × 144 × 100 mm (5.7 × 5.7 × 3.9 in)
• Weight: Approx. 3.4 kg (7.5 lbs)

• Certification: CE, UL, IEC 61850 (Optional), IEEE C37.90.1


369-HI-R-M-0-0-0-E -1.jpg


3. Core Features
• 12 RTD Channels: Real-Time Stator/Bearing Temperature Monitoring for Early Fault Detection.
• Enhanced Metering: Precise Power/Energy Tracking for Energy Efficiency Optimization.
• Advanced Diagnostics: Motor Health Reports & Predictive Maintenance Alerts to Extend Asset Life.
• Flexible Communication: Supports Industry-Standard Protocols for SCADA/PLC Integration.
• Easy Configuration: Enervista Software & Motor Settings Auto-Configurator for Quick Setup.
• Event Oscillography: Waveform Capture for Post-Fault Analysis & Root Cause Identification.
• Robust Protection: Comprehensive Fault Detection to Prevent Motor Damage & Production Loss.

• High Control Power Range: Compatible with Various Industrial Power Supplies for Global Applications.


369-HI-R-M-0-0-0-E -5.png


4. Typical Applications
• Power Generation: Boiler Feed Pumps, Induced Draft Fans, Condenser Pumps.
• Oil & Gas: Pipeline Compressors, Wellhead Pumps, Offshore Platform Motors.
• Metallurgy: Rolling Mill Motors, Furnace Blowers, Conveyor Systems.
• Chemical Industry: Reactor Agitators, Centrifugal Compressors, Process Pumps.
• Water & Wastewater: Large Sewage Pumps, Aeration Blowers, Sludge Conveyors.

• Mining: Hoist Motors, Crusher Drives, Ventilation Fans.

369-HI-R-M-0-0-0-E -4.png


5. Installation & Maintenance
• Mounting: Panel Mount (Standard 144×144 mm Cutout)
• Wiring: Screw Terminals for Power, CT/VT Inputs, RTDs, Digital I/O, Communication (Torque: 1.2 N·m)
• Configuration: Enervista 369 Setup Software (USB/RS485 Connection)
• Calibration: Auto-Calibration via Software; Verify CT/VT Accuracy Annually
• Diagnostics: Enhanced Faceplate for Real-Time Status; Event Log & Waveform Analysis for Troubleshooting

• Maintenance: Check Terminal Tightness, Update Firmware, Test Relay Outputs Periodically


369-HI-R-M-0-0-0-E -3.png
