Product Number:ABB 3HNA000512-001 Remote Channel controller module

Product Overview

I. Product Overview and Positioning

ABB 3HNA000512-001 is the fully compatible drive control unit (DCU) of ABB ACS880 series, belonging to the intelligent transmission module of Industry 4.0 grade. Its core positioning is:

High dynamic servo control: Supports real-time communication via EtherCAT/Profinet, suitable for precise positioning scenarios such as robots and CNC machine tools.

Multi-axis coordinated drive: Achieve torque/speed synchronization of multiple motors through DCC (Dynamic Transmission Chain) technology, with error.. 0.01%.

Extreme working condition compatibility: With IP55 protection and a wide temperature range design from -25°C to +60°C, it covers harsh environments such as steel, mining, and wind power.

Ii. Technical Parameters and Core Functions

Hardware specifications and performance

Parameter category specifications and performance

Model identification: 3HNA000512-001 (Compatible with ACS88-01/04/07 series, power coverage: 0.37-1600kW)

Control architecture: Dual-core DSP+FPGA heterogeneous computing platform, control cycle 50μs (servo mode)

Communication interfaces: EtherCAT (CiA402 driver protocol), Profinet IRT, Modbus TCP/RTU

Encoder feedback supports EnDat 2.2/Hiperface DSL/SSI (with a maximum resolution of 26 bits)

Dynamic response speed loop bandwidth 1.5kHz (servo mode), position loop delay 1ms

ABB 3HNA000512-001 Remote Channel controller module
